WE-D Digital Display Hydraulic Universal Testing Machine

WE-B series digital display hydraulic universal testing machine is mainly used for tensile， compression， bending and other mechanical property tests of metal materials. After adding simple accessories， it can test cement， concrete， brick， tile， rubber and their products.

Performance Characteristics of WE-D Digital Display Hydraulic Universal Testing Machine

1. The main engine adopts a four-column high-rigid frame structure， with stable support， stable loading and beautiful appearance;

2. The base of the main engine is made of QT500-7 precision casting， which reduces the operating noise of the equipment and improves the rigidity of the equipment;

3. Both the moving cross beam and the upper cross beam are precision casting and CNC precision machining to ensure the neutrality of the sample clamping;

4. The moving beam lifting system adopts grinding lead screws and precision gear reducers to reduce the noise generated when the beam is lifted;

5. The jaw seat with special structure design prevents damage due to the trumpet-shaped deformation of the jaw seat， and improves the service life of the equipment;

6. The jaw adopts dovetail groove structure， the hardness is as high as 58-62HRC， and it has the advantages of convenient installation， strong and durable;

7. The measurement and control system runs fast， the interface is mild， and has multiple sample information input modes， which can meet the test of different materials; 8. The sample information input is convenient， and the sample information with the same conditions can be input at one time to complete the test of multiple samples;

9. The test force display accuracy is high， and the resolution of the test force display is unchanged throughout the process， so as to ensure the accuracy of experimental data measurement;

10. The test data (test force， loading rate) and test curve are dynamically displayed on the screen in real time with the test process;

11. When the load exceeds 3-5% of the full scale， automatic overload protection stops.
